Combination Guy Attachments

Catalog
Number
Maximum Strand Diameter (inches) Strength Rating (pounds)

Dimensions (inches)

A

B

C

D

CGA-358 3/8 15,000 2-1/2 11/16 9/16 11/16
CGA-358-3 9/16 20,000 3 13/16 11/16 11/16
Category:

Description

MATERIAL: Ductile iron, grade 654512.
FINISH: Hot galvanized per ASTM A-153.

APPLICATION: A versatile guy attachment for light to medium loading. Can be used with strand or fiberglass strain insulator. Designed for use on round or flat surfaces.
