Copper Bonded Ground Rods

Catalog
Number
Diameter
(inches)
Length
(feet)
Standard
Bundle
GR-125C 1/2 5 5
GR-126C 1/2 6 5
GR-128C 1/2 8 5
GR-1210C 1/2 10 5
GR-585C 5/8 5 5
GR-586C 5/8 6 5
GR-588C 5/8 8 5
GR-5810C 5/8 10 5
GR-346C 3/4 6 5
GR-348C 3/4 8 5
GR-3410C 3/4 10 5

Description

MATERIAL: High strength carbon steel.
FINISH: Molecularly bonded electrolytic copper.

APPLICATION: Copper covered grounding electrode. Cold drawn for greater strength and rigidity with a uniform covering of molecularly bonded copper. Machined point for easier driving and chamfered top to reduce deformation.
