Description
MATERIAL: Ductile iron, grade 654512.
FINISH: Hot galvanized per ASTM A-153.
APPLICATION: For span, head and stub guying. Eyenuts are tapped to fit industry – standard bolts.
Eyenuts
Catalog Number |
Type |
Dimension (inches) |
|
Bolt Diameter |
Maximum Strand | ||
| TEN-12 | Thimbleye | 1/2 | 1/2 |
| TEN-58+ | 5/8 | 1/2 | |
| TEN-34+ | 3/4 | 1/2 | |
| TWN-58+ | Twineye | 5/8 | 5/8 |
| TWN-34+ | 3/4 | 5/8 | |
| TWN-10 | 1 | 5/8 | |
