Description
EQUIPMENT MOUNTING STRAPS: These brackets are available with or without mounting straps (pictured above). To order with straps add the mounting strap number to the bracket number. Example: CB-348-GL
GROUND LUGS: To order brackets with ground lugs (pictured on page A-5) add “GL” to catalog number. Example: CB-348-GL
Two Phase Brackets
MATERIAL: A36 hot rolled steel. All bolts, nuts and washers are steel.
FINISH: Hot dip galvanized per ASTM A-153.
EQUIPMENT MOUNTING HARDWARE: Consists of ½”x2″ captive carriage bolts with external tooth washers, split lockwashers and hex nuts.
POLE MOUNTING HOLES: All brackets are designed for mounting to pole with two 5/8″ diameter bolts.
Three Phase Brackets
MATERIAL: A36 hot rolled steel. All bolts, nuts and washers are steel.
FINISH: Hot dip galvanized per ASTM A-153.
EQUIPMENT MOUNTING HARDWARE: Consists of ½”x2″ captive carriage bolts with external tooth washers, split lockwashers and hex nuts.
POLE MOUNTING HOLES: All brackets are designed for mounting to pole with two 5/8″ diameter bolts.
